Basic Specs

KEYBOARD

QWERTY

MEDIA TYPE

TZe tape

AVAILABLE TAPE WIDTHS

3.5mm, 6mm, 9mm, 12mm,18mm

DIMENSION (WIDTH X DEPTH X HEIGHT)

187 mm x 72 mm x 178 mm

WEIGHT

0.76 kg

WARRANTY

1 Year Carry in Warranty by Brother Singapore Direct

Print Output

PRINT RESOLUTION

180dpi

PRINT SPEED

20mm/sec

NO. OF LINES PRINTABLE

18mm tape: 1 – 5 lines;

12mm tape: 1 – 3 lines;

9mm tape: 1 – 2 lines;

6mm tape: 1 – 2 lines;

3.5mm tape: 1 line

NUMBER OF CHARACTERS

908

NUMBER OF SYMBOLS

700

BAR CODE

1. CODE39

2. CODE128

3. EAN-8

4. EAN-13

5. ITF 2/5

6. UPC-A

7. UPC-E

8. CODABAR

9. GS1-128 (UCC/EAN128)

NUMBERING

Yes (1 to 99)

Media

TAPE CASSETTE

Up to 18mm

Functions

CUTTER

Manual

MULTI-BLOCK PRINTING

Yes

COPY PRINTING

Yes

MIRROR PRINTING

Yes

PREVIEW

Yes

Memory

FILE STORAGE

Up to 50 files

MEMORY BUFFER SIZE

Up to 280 characters

Power Supply

POWER SUPPLY

6 pcs of AA alkaline batteries (LR6), 6 pcs of AA Ni-MH batteries (HR6), or AC Power adapter (AD-E001A)

AUTO POWER-OFF

Battery: 5 min

AC Power adapter: 8 hours

AC ADAPTOR

AD-E001A

Interface

BUTTON

Keyboard

DISPLAY

16-character x 2 lines

BACKLIGHT

No

Connectivity

USB

Micro USB

version 2.0 (Full speed)

WIRELESS LAN

No
